GSH5速度传感器价格,GSH5速度传感器参数,GSH5速度传感器特点,GSH5速度传感器厂家,GSH5速度传感器规格-山东矿安机电皮带综保有限公司

产品介绍 Product introduction

有质量才有市场有改善才有进步 Only with quality can there be a market, and only with improvement can there be progress

该传感器可对任意绞车的钢丝绳进行跟踪监测，测速轮可进行灵活调整适合多种规格的钢丝绳，减震装置能使来自钢丝绳的跳动消除，彻底解决测速不稳的现象，同时还可以通过检测脉冲进行计算绞车箕斗的运行位置。该传感器可对任意绞车的钢丝绳进行跟踪监测，测速轮可进行灵活调整适合多种规格的钢丝绳，减震装置能使来自钢丝绳的跳动消除，彻底解决测速不稳的现象，同时还可以通过检测脉冲进行计算绞车箕斗的运行位置。

The sensor can track and monitor the wire rope of any winch, the speed measuring wheel can be flexibly adjusted, which is suitable for wire ropes of various specifications, and the damping device can eliminate the runout from the wire ropeAt the same time, the operation position of winch skip can be calculated by detecting pulse. The sensor can track and monitor the wire rope of any winch , the speed measuring wheel can be flexibly adjusted, which is suitable for wire ropes of various specifications. The damping device can eliminate the runout from the wire rope, completely solve the phenomenon of unstable speed measurement, andDetect the pulse to calculate the operation position of winch skip.

产品特点 Product introduction

质量出效益,点滴成江河 Quality brings benefits, and every drop becomes a river

GSH5转速传感器具有结构简单，安装方便，电路采模块化设计。整体封装。当皮带机正常运行时输出1Hz频率的方波信号，当
不符合额定值时转速传感器输出低电平。

Gsh5 speed sensor has the advantages of simple structure, convenient installation and modular circuit design. Overall package. When the belt conveyor operates normally, it outputs a square wave signal with a
frequency of 1Hz. When it does not meet the requirementsAt rated value, the speed sensor outputs low level.

产品性能 Product performance

质量意识在心中,产品质量在手中 Quality awareness in mind, product quality in hand

一综合保护

具有皮带机打滑、堆煤、超温、跑偏、烟
雾、撕带、急停、超温自动洒水等综合保
护功能。

二控制功能

具有逆煤流延时顺序起车，逆煤流顺序
停车，紧急停车等集中控制功能。

三警示功能

具有报警和通话功能

四系统节能

根据要求设置的开车传感器能实现随机开车，
具有显著的系统节能效果。

产品参数 Product parameters

性能稳定安全可靠 Stable performance, safe and reliable

防爆标志:	ExibI
大气压力:	80-106kPa
周围介质温度:	不高于+40℃，不低于5℃；
周围空气相对湿度:	不大于95%（20±5℃）；
电网电压允许波动范围:	-25% ～ +10%;
工作电压:	DC+12V;
电流:	≤80mA;
传感器与主机间连接电缆长度:	不超过500m;
在无显著摇动和冲击振动的地方;在无足以腐蚀金属和破坏绝缘的气体和蒸气的环境中;具有200-1000Hz 频率和继电器触点输出功能。
